SmartRay has expanded its advanced ECCO X sensor family with the launch of the ECCO X 050 and ECCO X 200. As a premier provider of high-precision automated optical inspection and inline metrology solutions, the manufacturer is building on the legacy of its acclaimed ECCO X technology platform. T
he new 3D laser profilers are engineered for unparalleled measurement certainty, robust performance, and maximum velocity across a diverse range of industrial inspection use cases.
Both models deliver high-speed, reliable inline scanning at demanding production speeds. They share the core, high-performance architecture of the ECCO X series, which boasts:
- A scan rate reaching up to 40 kHz
- Profile measurements with up to 4,096 points
- An impressive data throughput of up to 163 million 3D points per second
ECCO X 050: Micron-Level Metrology for Compact Spaces
Tailored for confined environments, the ECCO X 050 is specifically optimized for applications demanding exceptional dimensional accuracy. By combining an extraordinarily compact footprint with a mid-range field of view and micron-level resolution, the sensor ensures maximum measurement certainty where tolerances are tight. It provides outstanding repeatability for inline metrology tasks, capturing even the most microscopic deviations to guarantee optimal product quality.
Common applications and industries utilizing this compact model include:
- Consumer Electronics: Detailed 3D inspection of complex, miniature components and device housings.
- Electrical Connectors: Exact measurement of pin coplanarity, geometric attributes, insertion depth, and precise positions.
ECCO X 200: Large Field‑of‑View Measurement for Demanding Environments
Designed for large components and extended measurement distances, the ECCO X 200 enables fast, accurate inspection across wide fields of view without compromising data quality. Its robust, IP67‑rated housing makes it ideally suited for harsh industrial environments.
Typical industries and applications include:
- Battery Cell Connectors – Inline inspection of battery cell and module interconnects as well as large current‑carrying structures
- Steel and Welding Applications – Reliable 3D measurement of weld seams, seam geometry, and material transitions
- Automotive Industry – Inspection of body‑in‑white structures, assemblies, and large stamped or welded components
- Rail and Transportation – Precision measurement of large parts and structural elements in rail and heavy‑industry applications
The ECCO X 200 is supplied with a 660 nm laser in Laser Class 3R. Laser Class 2 configurations are available on request.
